The latest generation of SRT servos provides you with the performance you need for any scale vehicle\ Air Plane\Boat\Robot application. are standard size servos for High-Voltage applications up to 8.4V, feature all metal case construction for the ultimate performance.
Features:
- Special 1/12 pancar servo
- Supporting SXR, SFR, SR, SSR multiple ultra high speed modes
- Incredible efficiency and low power consumption
- 2 μsec Dead Band
- 1-Year Limited Warranty
Specifications:
| Type |
Digital |
| Bearing |
Dual |
| Motor Type |
Coreless |
| Gear Type |
Metal |
| Gear Material |
Titanium & Steel |
| Control System |
Pulse width control |
| Working Frequence |
1520μs / 333hz |
| Operating Voltage |
dc6.0-8.4v |
| Operating Temperature Range |
-10 to + 60 degree |
| Operating Speed (6.0V) |
0.07 sec/60 degrees at no load |
| Operating Speed (7.4V) |
0.065 sec/60 degrees at no load |
| Operating Speed (8.4V) |
0.055 sec/60 degrees at no load |
| Stall Torque (6.0V) |
7.0kg.cm (97.2 oz/in) |
| Stall Torque (7.4V) |
8.0kg.cm (111.1 oz/in) |
| Stall Torque (8.4V) |
9.0kg.cm (125.0 oz/in) |
| Potentiometer Drive |
Direct Drive |
| Dimensions |
28.5x13.4x29.0 mm /1.12x0.53x1.14 in |
| Weight |
28.0g (1.0 oz) |
| Connector Wire Length |
JR 170 mm |
